Electrical Release - Lac-Mégantic
(1 000 NOTCHES)
BHR224
| DIMENSIONS | SINGLE (12" X 24") |
| MANIFOLD NUMBER OF INPUTS | 6" x 12" 4 x 1 " |
| SAP OUTLET HEIGHT | 1 x ¼ " 24" |
| VACUUM PUMP OUTPUT | 1 x 1 ½ " |
BHR216
| DIMENSIONS | SINGLE (12" x 18") |
| MANIFOLD NUMBER OF INPUTS | 6" x 12" 4 x 1" |
| SAP OUTLET HEIGHT | 1 x 2" 20" |
| VACUUM PUMP OUTPUT | 1 x 1 ½ " |
(1 500 NOTCHES)
BHR224-1
| DIMENSIONS | SINGLE (12" X 36") |
| MANIFOLD NUMBER OF INPUTS | 6" x 27" 6 x 1 " |
| SAP OUTLET HEIGHT | 1 x 1 ¼ " 40" |
| VACUUM PUMP OUTPUT | 1 x 1 ½ " |
(5 000 NOTCHES)
BHR225
| DIMENSIONS | SINGLE (18" X 24") |
| MANIFOLD NUMBER OF INPUTS | 6" x 27" 8 x 1 ¼ " |
| SAP OUTLET HEIGHT | 1 x 2 " 33" |
| VACUUM PUMP OUTPUT | 1 x 3 " |
*EMERGENCY STOP BUTTON
(10 000 NOTCHES)
BHR227-36
| DIMENSIONS | SINGLE (18" X 36") |
| DIMENSIONSMANIFOLD NUMBER OF INPUTS | 6" x 42" 12 x 1 ¼ " |
| SAP OUTLET HEIGHT | 1 x 2 " 33" |
| VACUUM PUMP OUTPUT | 1 x 3 " |
*EMERGENCY STOP BUTTON
(15 000 NOTCHES)
BHR227-48
| DIMENSIONS | SINGLE (18" X 48") |
| DIMENSIONSMANIFOLD NUMBER OF INPUTS | 6" x 52" 15 x 1 ¼ " |
| SAP OUTLET HEIGHT | 1 x 2 " 33" |
| VACUUM PUMP OUTPUT | 1 x 3 " |
*EMERGENCY STOP BUTTON
(20 000 NOTCHES)
BHR227-60
| DIMENSIONS | SINGLE (18" X 60") |
| DIMENSIONSMANIFOLD NUMBER OF INPUTS | 6" x 60" 18 x 1 ¼ " |
| SAP OUTLET HEIGHT | 1 x 2 " 33" |
| VACUUM PUMP OUTPUT | 1 x 3 " |
*EMERGENCY STOP BUTTON
OPTIONS
| ADDITION OF SAP ENTRANCE TO THE MANIFOLD |
| CHANGE OF THE DIMENSIONS OF THE INLETS AT THE MANIFOLD |
| DIAMETER OF THE NON-STANDARD MANIFOLD |
| LENGTH OF THE NON-STANDARD MANIFOLD |
| ADDITION OF A 2ND SWITCH FOR WATER PUMP |
| ADDITION OF THE EMERGENCY STOP BUTTON |
| ADDITION OF AN ANTI-ICE GRID (DEPENDING ON SIZE) |
| 6" X 12" |
| 6" X 27" |
| 6" X 42" |
| 6" X 52" |
| 6" X 60" |
